Ringfeder 7013.1 32x60 Locking Assembly
Ringfeder 7013.1, 32d, 60D self-centering lock assemblies are intended for enhanced strength, optimal for the highest rotational speeds and radial loads. They are used for crane running wheels, couplings, gearwheels, flywheels and fan wheels. You can download the product's 3D model below.
MPN:RfN 7013.1-32x60
0 Reviews
Specifications
inner diameter inch
1.26
outer diameter inch
2.362
db1
2.677
overall length
1.457
overall length without screws
1.22
width of ring
0.854
transmissible torque at given ta
546
pw
39130
pn
15942
ta
13
dn min bei 400
2.953
max. transmissible torque ft lbs
597
collar outer diameter
2.677
surface pressure on shaft at given ta
39130
surface pressure on hub at given ta
15942
max. tightened torque of the clamping screws
13
series
RfN7013.1
d mm
60
l mm
37
l1 mm
31
t nm
740
pw nmm2
270
pn nmm2
110
ta nm
17
dn min bei rp02 400 nmm2 mm
75
tmax nm
810
video
db1 mm
68
l4 mm
25.7
