Please Note: Photo may not represent actual item, please refer to title and product specifications for all details.
Thomson End Supported Roundrail Linear Guide System 1BA24AH0L72.000
Linear Guide, Single Shaft, 1BA, Industry Standard Round Shafts, ASB Support, 2 Pillow Blocks, 1.5 in, 6160 lbf Dynamic Load Capacity. RoundRail linear guides feature Thomson’s patented self-aligning Super Ball Bushing Bearings with up to 216X the life or 6X the load capacity of conventional bearings. It is end supported for gantry style or ‘bridge’ applications and it's used to provide increased stability or torque resistance in linear system applications. You can download the product's 3D model below.
MPN: 1BA24AH0L72.000
Specifications
| diameter | 38 mm (1.500 in) |
| shaft material | Steel |
| support material | Aluminum |
| block material | Aluminum 6061, Delrin, Nitrile |
| max temperature | 85 °C (185 °F) |
| type | End Supported, Two Pillow Blocks |
