Please Note: Photo may not represent actual item, please refer to title and product specifications for all details.
Thomson Dual Shaft Bearings Roundrail Linear Guide System 2DA1600BL72.000
Linear Guide, Dual Shaft, 2DA, Dual Shaft Rail with Integrated Carriage, Continuous Support, Wide Carriage, 1 in, 5400 lbf Dynamic Load Capacity. This performance proven linear guide has an extremely low profile and features external rails with maximum bearing spacing. This provides the user with high pitch, yaw and roll moment capability. The inherent, self-aligning design of the Super Smart Ball Bushing Bearings allow for more deviation in the flatness of the mounting surface. This can dramatically reduce the installed cost of the linear guide. The base extrusion has a reference edge for registration in your machine. Unlimited travel lengths can be realized by combining base and shaft segments. The shafts and bases are staggered to allow keying of the subsequent stage. You can download the product's 3D model below.
MPN: 2DA1600BL72.000
Specifications
| diameter | 25 mm (1.000 in) |
| shaft material | Carbon Steel (AISI 1566), Aluminum 6061 |
| environment | Standard |
| carriage material | Carbon Steel (AISI 1566), Aluminum 6061 |
| max temperature | 85 °C (185 °F) |
| type | Dual Shaft Bearings, Dual Shaft Rail, Standard Carriage |
