Betex Induction Heating Generator 2.5, 44kW 450V
Induction Heating Generators 2.5 44kW 450V, that provide smart and eco-friendly way of heating and safe, energy efficient operation. The heaters applications include mounting and dismounting of bearings, bearing houses, sleeves and power transmissions components, mounting of gears, couplings and others.
Min. winding diameter flexible Inductors 44kW
|
Length m / °C |
Ø Cable |
Min. Winding- diameter |
|
15/20/25/30m¹ /180°C |
Ø 19 mm |
ca. 140 mm |
|
15/20/25/30m¹ /300°C |
Ø 28 mm |
ca. 220 mm |
MPN: 32544450
Specifications
| USB connection | No |
| signalling by operational state | green flashing light |
| signalling by error message | red continuous light/acoustic signal |
| ampere | 59 |
| signalling by end heating cycle | green continuous light/acoustic signal |
| Mpn | 32544450 |
| trolley | option |
| frequency Hz | 50/60 |
| power kW | 44 |
| accuracy C | 35 |
| display mm | 35 |
| delta T | Yes |
| temp. sensor max 300C | Yes |
| heating curve in display | Yes |
| heat log | No |
| setpoint power | Yes |
| setpoint temperature | Yes |
| extra thermo couple input | Yes |
| generator mm | 600x650x580 |
