Rosta Rubber Suspension Units DR-S
The housing of DR-S type of Rubber Suspension Units are made of steel, inner square section is made of steel tube for mounting ''plug-in'' lever arms on one or both sides. The inserted part should be at least three times longer than the clearance ''C''.
DR-S type lever arms can be mounted through bolt and the levers are fixed by frictional force at any position within 3600. Both ways of fixation are particularly well suited for motions at the plus or minus angular range (no alternating motions across the neutral axis = play). All metal parts are paint-finished.
MPN: 01 021 001
Specifications
| Nm ± 15° | 1.6 |
| S | 11 |
| L | 20 |
| Weight (kg) | 0.04 |
| L1 | 25 |
| D | 20 |
| Nm ± 25° | 3.5 |
| Type | 11 x 20 |
| C | 8 |
| Nm ± 30° | 4.8 |
| Nm ± 20° | 2.4 |
