Rosta Rubber Suspension Units DW-S
DW-S 15-38 Rubber Suspension Units housings are made from light alloy profile and are equipped with lateral fixation flanges, including fixation bores for direct mounting to the machine parts on request.
The inner square sections are made from electrodeposited galvanic zinc coating steel. The inner square can be utilized for mounting ''plug-in'' lever arms on one or both sides.
MPN: 01 111 201
Specifications
| Weight (kg) | 0.06 |
| L1 | 30 |
| L | 25 |
| S | 15 |
| O | 3 |
| Q | 15 |
| ØI | 7 |
| H | 65 |
| G | 50 |
| E | 29 |
| C | 11 |
| Type | 15 x 25 |
| Nm ± 30° | 8.2 |
| Nm ± 5° | 0.7 |
