Rosta Rubber Suspension Units DO-A
The housing up to 45 size of Rubber Suspension Units DO-A are made from light alloy profile, size 50 is made out of spheroidal graphite cast iron, inner square section - light alloy profile with four ''throughbores''.
The unit levers can be mounted on one or both sides by means of bolts. It provides an excellent attachement without movement, which is very essential in order to transmit alternating motions passing the neutral axis in either direction. All metal parts are paint-finished
MPN: 01 041 001
Specifications
| Weight (kg) | 0.1 |
| Type | 15 x 25 |
| øA | 5 |
| B | 10 |
| D | 28 |
| E | 25.5 |
| F | 53.5 |
| S | 15 |
| G | - |
| L | 25 |
| H | - |
| L1 | 30 |
